Thoracic Drainage Catheter Without Trocar
Infant Feeding Tube with Graduation
Ref Code: 40180-40186
Designed for post-operative secretion and removal of body fluids during cardio- thoracic and thoracic Surgery.
Features and Benefits
- Made of medical grade biocompatible, non-toxic PVC.
- Proximal end fitted with tapered tongue connector which provides forceps grip and assist in atraumatic insertion.
- Open, distal end, smoothly finished large eyes for efficient drainage.
- X-ray opaque line throughout catheter length for detection and placement.
- Graduated at 2cm intervals from the beginning of eyes.
- Packed with matching size tapered connector which facilitates easy connection to drainage system.
- Single Use, Non-Pyrogenic, Sterile.
Options available: Right angled catheter for thoracic drainage from the deeper sites of pleural cavity.
Specifications
| Ref/Art No. | Variant | Available in Sizes | Length | Packing Inner/Outer unit |
|---|---|---|---|---|
| SD0201 | Without Trocar Straight | 10FG, 12FG, 14FG, 16FG, 18FG, 20FG, 22FG, 24FG, 26FG, 28FG, 30FG, 32FG, 34FG, 36FG, 38FG, 40FG | 45cm | 25/250 |
| SD0202 | Without Trocar curved | 10FG, 12FG, 14FG, 16FG, 18FG, 20FG, 22FG, 24FG, 26FG, 28FG, 30FG, 32FG, 34FG, 36FG, 38FG, 40FG | 45cm | 25/250 |
