IV Can
Infant Feeding Tube with Graduation
Ref Code: 40180-40186
Art Reference No. IT0119
Features and Benefits
- New miniature design for cannulation of small & soft veins, especially in pediatric use.
- Provides a small projection on the main body for ease of handling during cannulation, yet non-interfering during taping and post-cannulation management.
- Mini-size flexible angled and grooved wings for effective and secure fixation.
- Simple design without any injection port.
- Single use, non-pyrogenic, sterile.
Specifications
| Ref/Art No. | Gauge | Colour Code | Ext. Dia. (mm) | Catheter Length (mm) | Flow Rate (ml./min) | Packing (Inner/Outer unit) |
|---|---|---|---|---|---|---|
| IT0119-14 | 14G | Orange | 2.1 | 45 | 300 | 100/1000 |
| IT0119-16 | 16G | Grey | 1.7 | 45 | 200 | 100/1000 |
| IT0119-17 | 17G | White | 1.5 | 45 | 140 | 100/1000 |
| IT0119-18 | 18G | Green | 1.3 | 45 | 90 | 100/1000 |
| IT0119-20 | 20G | Pink | 1.1 | 32 | 60 | 100/1000 |
| IT0119-22 | 22G | Blue | 0.9 | 25 | 33 | 100/1000 |
| IT0119-24 | 24G | Yellow | 0.7 | 19 | 20 | 100/1000 |
| IT0119-26 | 26G | Violet | 0.6 | 19 | 15 | 100/1000 |
